14" Manual Creasing Machine C35M2

14" Manual Creasing Machine C35M2

14
CategoriesCreasing Machine
AlbumView larger image
BrandSUPU
ModelC35M2
Working width350mm
Max creasing thickness0.36mm
creasing depth0.4mm
Creasing length320mm
Creasing width1.3mm
Thickness of sheets<=275g
Machine dimension600x395x125mm
Machine weight8.8kg
FOB portNingbo/Shanghai
Terms of PaymentT/T
Update Time2018-10-23
Detail Information

14" MANUAL CREASING MACHINE C35M2

The manual creasing machine is suitable for series products with multi-variety, small batch indentation and folding. The indentation line is clear and beautiful. When using indentation such as coated paper, special paper and paper, there will be no burrs or folds after folding. Crack phenomenon. Different thickness indentation steel lines and different width indentation molds can be replaced.

  • Manual creasing simple operation

  • Creasing impress round slot

  • Middle format size 350mm can operate A4 A5 B5 size paper

  • Adjustable positioning button

  • All metal construction make it durable

Maximum:


  • Thickness <=275g


  • Round slot


  • Width is 350mm

The all-metal structure and integrated welding work platform ensure stable operation and durability; the card slot type magnetic positioning block and the quick-change indentation die ensure accurate indentation effect;


Model Name

C-35M2

Working width

350mm

Creasing thickness

0.36mm

Creasing depth

0.4mm

Creasing length

320mm

Creasing width

 1.3mm

Thickness of sheets

<=275g

type of paper stop

round slot

The direction of installation of the creasing machine should be conducive to safe operation, with the operator facing the wall, and the minimum clear distance from the surrounding buildings and facilities is less than 0, 8m.

The layout of the workshop equipment using the creasing machine should be reasonable, the road surface is flat, and the passage is smooth. The creasing machine should be in good condition, complete technical data, complete special tools, intact
